ARINC 615 & 615A USB Micro PDL

ARINC 615 & 615A USB based Portable Data Loader

The AIT Micro Portable Data Loader (AIT-uPDL) is a ruggedized, portable “intelligent cable” solution that can be used in conjunction with a USB connection to any Windows PC, Laptop, or Tablet to support ARINC 615, ARINC 615A, and ARINC 844 software data load applications. The AIT-uPDL is coupled with AIT’s Data Loader web browser based “App” to provide an easy to use Data Loader solution which can be easily integrated into existing maintenance laptops or tablets. Dedicated internal mass storage (32GB and 64GB options available) allows all loadable software to reside on the AIT-uPDL. The AIT-uPDL supports ARINC 615-3/4 loads over ARINC 429 as well as ARINC 615A (-1,-2,-3) loads over Ethernet and ARINC 664.

The AIT-uPDL can be connected directly to the standard ARINC 615 53-pin connector of the aircraft or adapted to other connections types with existing cable assemblies such as ARINC 615 to ARINC 603 adapter cables.
uPDL-with-USB-Cable
Get uPDL-615 Datasheet

Request Quote


Key Features

• Supports 615‐3/4 Data Loader operations using ARINC 429
• Supports 615A (‐1, ‐2, & ‐3) Data Load operations over Ethernet & ARINC 664 networks
• Standard ARINC 615 53‐pin connector for direct connection to aircraft and compatibility with ARINC
615 to 603 adapter cables
• Optional Network Loadable Software Distribution applications available (but NOT required!)
• 32 GB (or optional 64 GB upgrade) built‐in mass storage dedicated to loadable software parts
• Verifies and Validates software parts prior to load operations
• Powered via USB connection (no aircraft or external power required)
• Includes Intuitive & easy to use graphical user interface (web browser based)
• Simple single button load operations with concise status indication
